RO42449 - H0-Single slip turnout EKW15, no mechanism

Single slip turnout EKW15, without turnout mechanisms. Standard design with internal switch rails.

Length 230 mm (standard length), crossing angle 15°, branch radius 531 mm.

For diagonal installation two D4 and one D12 are included.

Suitable turnout mechanisms (2 pieces are required):
40295 (electric turnout mechanism left)
or 40297 (manual turnout mechanism left)
or 10030 (below baseboard mechanism).

■ Frog and wheel guide completely revised
■ Prototypical passing of the frog possible
■ Groove width in the frog area according to NEM
■ Polarisation of the turnout frog possible in combination with electric ROCO turnout drives
